Unbalanced Type FTTR gpon splitter

Unbalanced Type FTTR gpon splitter

Description

Unbalanced type FTTR fiber optic GPON splitter is an indoor optical routing product that provides increased internet speed, extended Wi-Fi range, and the ability to control smart appliances.

GET A QUOTE Watch Video

Details

Unbalanced type FTTR fiber optic GPON splitter is an indoor optical routing product that provides increased internet speed, extended Wi-Fi range, and the ability to control smart appliances.

We offer competitive pricing and customized services to meet your specific needs.

Our factory can meet even the most demanding requirements with a large production capacity of up to 50,000 pieces per month.

Technical Data

1xN PLC Splitter Specification
Operating Wavelength(nm) 1260~1650
Fiber Type G657A1 or as customers' order
Port Configuration 1x2 1x4 1x8 1x16 1x32 1x64 1x128
Insertion Loss (dB) 3.8/4.0 7.1/7.3 10.2/10.5 13.5/13.7 16.5/16.9 20.5/21.0 23.8/24.2
Loss Uniformity (dB) 0.4 0.6 0.8 1.2 1.5 2.0 2.5
Polarization Dependent Loss(dB) 0.2 0.2 0.2 0.25 0.3 0.35 0.4
Wavelength Dependent Loss(dB) 0.3 0.3 0.3 0.5 0.5 0.5 0.5
Temperature Dependent Loss (-40~85 ) (dB) 0.4 0.4 0.4 0.5 0.5 0.5 0.5
Return Loss (dB) 55/50
Operating Temperature -40~+85
Directivity (dB) ≥ 55
Storage Temperature -40~+85

Info & Guides

FEATURE

· Wide operating wavelength range:from 1260nm to 1650nm
· Wide Operating Temperature: from -40ºC to 85ºC
· Good channel-to-channel uniformity
· High reliability and small size
· Adopt high strength stainless steel, pass salt spray test
· Adopt 100% new raw material, ROHS compliance
· Low Insertion loss&Low PDL Compact Design



APPLICATIONS

· FTTx
· Cable television (CATV)
· Local area networks (LAN)
· Test equipment
· Passive optical networks(PON)
