Fiber Optic Fusion Splicing Machine - 6481 Series

Fiber Optic Fusion Splicing Machine - 6481 Series

Description

Discover the 6481 Series Fiber Optic Splicing Machine, a reliable, versatile tool for joining and protecting various fiber optic cables. Experience its strong adaptability, high reliability, and user-friendly features.

GET A QUOTE Watch Video

Details

Introducing the 6481 Series Fiber Optic Splicing Machine, designed for high-performance splicing and protection of a range of fiber optic cables, including communication and erbium-doped fibers.

Enjoy its excellent adaptability, reliability, and resistance to dust, water, and impact in diverse environments.

Splicing and Heating Modes

  • Cater to various splicing needs
  • High-precision ceramic V-groove for easy, accurate fiber placement
  • Easy-to-clean design
  • User-Friendly Interface

Touch screen display

  • Intuitive graphical menu
  • Reliable Power

Large-capacity modular lithium battery

Ideal for long-term outdoor projects

At Fibeye, our priority is meeting your needs with reliable, efficient fiber optic splicing solutions. The 6481 Series Fiber Optic Splicing Machine exemplifies this commitment, offering high-performance features in a compact, user-friendly design. Contact us today to learn more.

Packing







Technical Data

Specification 6481A9+ 6481B5+
Motor Quantity Six motors Four motors
Alignment Accurate core alignment, cladding alignment, manual alignment Cladding alignment, manual alignment
Applicable Fiber Ordinary fibers, ribbon fibers, and jumper wires compliant with ITU-T G.651~653, G.655 and G.657
Fiber Diameter Cladding: 80~150μm, Coating: 0.1~3mm
Splicing Loss (Typical) 0.02dB (SMF); 0.01dB (MMF); 0.04dB (DSF); 0.04dB (NZDSF) 0.03dB (SMF); 0.02dB (MMF); 0.05dB (DSF); 0.05dB (NZDSF)
Splicing Time (Typical) 7s (Fast mode)
Heating Time Less than 15s (40mm heat shrink tube, 23℃)
Tension Test 1.96~2.25N
Heat Shrink Tubing 60mm, 40mm, and a range of heat shrink tubing
Display High-performance 4.3-inch LCD screen
Splicing Record 30000 sets/200 images 30000 sets
Maximum Power 80W
Battery Capacity 6400mAh 5200mAh
Battery Life Cyclic charging up to 300~500 times, user-replaceable
Electrode Life Typical 3000 times, user-replaceable
Work Lighting Built-in high-brightness, wide-range lighting
Operating Environment Temperature: -10~50℃; Humidity: 0~95% RH; Altitude: 0~6000m
Operating Interface GUI graphical user interface
External Power Supply AC: 100~240V, 60Hz, 0~1.5A; DC: 10~15V
External Interface USB/SD
Dimensions 120mm(W) x 130mm(H) x 154mm(D) (excluding rubber shock pad)
Weight 1.8kg (without battery), 2.1kg (with battery) 1.65kg (without battery), 1.95kg (with battery)

Info & Guides

Features

  • Compact and lightweight design
  • Quick 7-second fusion splicing and 15-second heat shrinking (for 40mm heat shrink tubes)
  • High-precision ceramic V-groove and multi-functional clamp for accurate fiber placement
  • Automatic fusion splicing and intelligent heat shrinking
  • USB and SD card interfaces for automatic software upgrades
  • Built-in modular lithium battery for at least 220 cycles of fusion splicing and heat shrinking
  • User-friendly touch screen display with graphical interface
  • Dustproof, waterproof, and shockproof for strong adaptability
  • Suitable for multiple fiber splicing and heat shrinking applications
  • Sturdy and durable for use in various environments
